SITE OVERVIEW: Capacity - Supporting a total of 270 racks in 48U 600mm x 1,000mm up to 7kW dual diverse power supplies. Available in ¼, ½ and full rack. Configuration - 1 Secure Data Hall - racks available in Amp, kW per annum and kWh models in singular racks or rows. Support - 24x7 on-site remote hands, monitoring and support available to all customers. On-site Cloud, Managed Services and Colocation. Security - 24x7 manned site with HD CCTV cameras, PAC access controlled into each area of the site, on-site provisioning and technical support teams. Power - 1,500kVA incoming supply from SSE to on-site substation and transformer. Cooling - Blended N+1 Chilled Water and Free Air redundant cooling solutions to 1,100kW. UPS - N+1 Modular PowerWAVE DPA high efficiency units with up to 15 minutes autonomy. Standby Generation - 6 x 500kVA Standby Rated units in N+1 configuration.
READING EAST 1 SITE SPECIFICATIONS Total Technical DC Sq Ft - 7,500 No of Data Halls - 1 Total Rack Capacity - 270 Building Floors - 1 Floor Void - 500mm Tier Rating - Tier 2 Total Power Provision - 1.5MW Total Power Protection - N Total UPS Provision - 1.2MW Total UPS Protection - N+1 Rack Provision - Single 16Amp or 32Amp Total Generator Provision - 2.4MW Total Generator Protection - N+N Total Generator Fuel Storage - 11,000 Litres Total Cooling Provision - 1.1MW Total Cooling Protection - N+1 Cooling Type - Chilled Water with Free Cooling CCTV - Total Cameras - 9 Cameras CCTV - Retention Period - Minimum 45 Days Access Control Type - Swipe Entry/Exit Access Control - Retention Period - Minimum 6 Months Fire Protection Systems - Floor and Ceiling Sensors/VESDA system Fire Suppressant Systems on-site - FM200
READING EAST 1 SITE COLOCATION PROPOSITIONS Rack Capacity - 270 1/4 Rack 1/2 Rack Full Rack Oversized Rack Dual PDU Cage 1Mb - 1Gb Transit Dark Fibre Site Backhaul Carriers - 9 PCI-DSS SP 2.0 ISO 27001:2013 Managed Server Colocation Backup DC Connectivity On-Net Services - BT, Virgin Media, KCOM, Vodafone, GEO, City Fibre Services, Colt, Level 3
POWER & GENERATORS To eliminate risk from outage or power failure, the site uses diverse supplier feeds from multiple grid points ensuring there is no single point of failure. The site will provide 2N+1 redundant power systems and power feeds up to 10kW per racks to ensure continuous power.
FIRE DETECTION & SUPPRESSION Ensuring our infrastructure and customer equipment operate safely is one of our greatest concerns. The facility is equipped with VESDA fire detection which continuously sample the air for smoke particles. In the event of an alert we have installed a FM200 suppression system.
DATACENTRE FACILITIES Pulsant have built a number of client facilities into the site to ensure any time you spend on-site is comfortable. There is ample provision for client IT staff who may be required on-site, this includes parking, rest rooms, kitchen, build facilities, dedicated offices and meeting rooms.
COOLING & PERFORMANCE Energy is vital to power and cool servers, we reduce energy consumption and costs by using ultra-efficient systems and advanced cold aisle and pod technology.
MULTI LEVEL SECURITY Pulsant do everything possible to prevent unauthorised access to the site, buildings and data halls as well as to the rack housings themselves. We have systems in place to identify and react to threats so that your infrastructure is protected from theft, damage or interference. The site is a PCI DSS Level 1 compliant facility.
NETWORK & CONNECTIVITY When creating the data campus we needed to ensure we had ultra-fast connectivity with low latency to London locations. We achieved this as the site houses diverse network connectivity via Dark Fibre to multiple London points of presence with 2ms of network latency.
